QUESTION: 16

A site needs to terminate client HTTPS traffic at the BIG‐IP and forward that traffic unencrypted. Which two are profile types that must be associated with such a virtual server? (Choose two.)

TCP
HTTP
HTTPS
ClientSSL
ServerSSL

Answer(s): A,D

Reveal Solution Next Question

QUESTION: 17

Which three statements describe a characteristic of profiles? (Choose three.)

Default profiles cannot be created or deleted.
Custom profiles are always based on a parent profile.
A profile can be a child of one profile and a parent of another.
All changes to parent profiles are propagated to their child profiles.
While most virtual servers have at least one profile associated with them, it is not required.

Answer(s): A,B,C

Reveal Solution Next Question

A virtual server is defined using a source‐address based persistence profile. The last five connections were A, B, C, A, C . Given the conditions shown in the graphic, if a client with IP address 205.12.45.52 opens a connection to the virtual server, which member will be used for the connection.

10.10.20.1:80
10.10.20.2:80
10.10.20.3:80
10.10.20.4:80
10.10.20.5:80

Answer(s): B

Reveal Solution Next Question

QUESTION: 19

How is persistence configured?

Persistence is an option within each pool's definition.
Persistence is a profile type; an appropriate profile is created and associated with virtual server.
Persistence is a global setting; once enabled, load‐balancing choices are superseded by the persistence method that is specified.
Persistence is an option for each pool member. When a pool is defined, each member's definition includes the option for persistence.

Answer(s): B

Reveal Solution Next Question
