Free 350-501 Exam Questions and Answers | by Exam-Dumps.net (Page: 2)

QUESTION: 6

You are configuring MPLS traffic-engineering tunnels in the core.
Which two ways exist for the tunnel path across the core? (Choose two.)

The dynamic path option is supported only with IS-IS.
Tunnels can be configured with dynamic path or explicitly defined path.
A zero bandwidth tunnel is not a valid option.
The bandwidth statement creates a “hard” reservation on the link.
Tunnel links inherit IGP metrics by default unless overridden.

Answer(s): B,E

Reveal Solution Next Question

QUESTION: 7

Which configuration mode do you use to apply the mplsldp graceful-restart command in IOS XE Software?

MPLS LDP neighbor
interface
MPLS
global

Answer(s): D

Reference:

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_ha/configuration/xe-3s/mp-ha-xe-3s-book/mp-ldp-grace-rstrt.html

Reveal Solution Next Question

QUESTION: 8

After you analyze your network environment, you decide to implement a full separation model for Internet access and MPLS L3VPN services. For which reason do you make this decision?

It enables EGP and IGP to operate independently.
It enables you to choose whether to separate or centralize each individual service.
It is easier to manage a system in which services are mixed.
It requires only one edge router.

Answer(s): A

Reveal Solution Next Question

QUESTION: 9

Which statement about the Cisco MPLS TE forwarding adjacency feature is true?

It enables the MPLS core to use EIGRP as the routing protocol.
It enables the Cisco MPLS TE tunnel to be advertised into the running IGP.
It enables the tailend router to advertise routes to the headend router over the tunnel.
It enables the headend and tailend routers to establish a bidirectional tunnel.

Answer(s): B

Reference:

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/mp_te_path_setup/configuration/xe-16/mp-te-path-setup-xe-16-book/mpls-traffic-engineering-forwarding-adjacency.pdf

Reveal Solution Next Question

QUESTION: 10

While implementing TTL security, you issue the PE(config-router-af)#neighbor 2.2.2.2 ttl-security hops 2 command.After you issue this command, which BGP packets does the PE accept?

to 2.2.2.2, with a TTL of 2 or more
from 2.2.2.2, with a TTL of less than 2
to 2.2.2.2, with a TTL of less than 253
from 2.2.2.2, with a TTL of 253 or more

Answer(s): D

Reference:

https://www.cisco.com/c/en/us/td/docs/ios/12_2sx/feature/guide/fsxebtsh.html#wp1059215

Reveal Solution Next Question
