Dell D-XTR-DS-A-24 Exam (page: 2)
Dell XtremIO Design Achievement
Updated on: 12-Feb-2026

Explanation:

The Dell EMC XtremIO X2 storage array offers flexible scaling options with building blocks called X-

Bricks1. The system can start with a single X-Brick and scale up to 72 SSDs for a single X-Brick1.
When additional performance and capacity are required, the system can be expanded by adding additional X-Bricks1.

Among the options provided, VMware is the host OS that supports both 512 bytes and 4 KB XtremIO logical block (LB) volumes23. VMware vSphere 6.7 and later versions support both 512-byte and 4K logical block sizes23. This is because VMware ESXi detects and registers the 4Kn devices and automatically emulates them as 512e3.

The other options, while they may be part of the overall process, are not specifically known to support both 512 bytes and 4 KB XtremIO logical block (LB) volumes:

Linux typically supports multiple file system block sizes of 512, 1024, 2048, and 40964. However, it's not specifically mentioned that it supports both 512 bytes and 4 KB XtremIO logical block volumes5.

IBM AIX also supports multiple file system block sizes of 512, 1024, 2048, and 40966. But again, it's not specifically mentioned that it supports both 512 bytes and 4 KB XtremIO logical block volumes7.

HP-UX does not specifically mention support for both 512 bytes and 4 KB XtremIO logical block volumes89.

Therefore, the verified answer is A. VMware, as it is the host OS that supports both 512 bytes and 4 KB XtremIO logical block (LB) volumes23.

Explanation:

Explore

I/O Elevators refer to the I/O scheduling algorithms used in operating systems to control how I/O operations are submitted to storage12. These algorithms, also known as elevators, determine the order in which I/O requests from different processes or devices are serviced by the underlying hardware, such as hard drives or solid-state drives (SSDs)12. The goal of these algorithms is to improve the efficiency of data access and reduce the time wasted by disk seeks3.

The other options provided are not typically referred to as I/O Elevators:

Option OB, "The maximum number of consecutive `sequential' I/Os allowed to be submitted to storage", refers to a specific parameter of a storage system, not an I/O Elevator4.

Option OC, "Setting which controls for how long the ESX host attempts to login to the iSCSI target before failing the login", refers to a specific setting in ESXi host configuration, not an I/O Elevator567.

Option OD, "The amount of SCSI commands (including I/O requests) that can be handled by a storage device at a given time", refers to the command handling capacity of a storage device, not an I/O Elevator89.

Therefore, the verified answer is A. I/O scheduling algorithm which controls how I/O operations are submitted to storage, as it accurately describes what I/O Elevators are according to the Dell XtremIO Design Achievement document10 and other sources123.

Explanation:

The Oracle Redo Log block size is recommended to be set to 8 kB. This is based on the best practices for Oracle 19c Database, where it was found that increasing the size of the Oracle redo logs can improve database performance12. However, it's important to note that not every workload will show significant performance increase when increasing the size of the redo logs. Customers should evaluate the AWR to determine if the redo logs have an associated high number and duration of wait times. If the redo logs show a possible bottleneck, then increasing the size of the redo logs could improve performance2.

Explanation:

The SCSI DIFF instruction is used to build a bitmap of the changes between the first snapshot and subsequent snapshots when RecoverPoint is used with XtremIO1.

The DIFF protocol is a vendor-specific SCSI command which RecoverPoint uses to query XtremIO in order to obtain a bitmap of changes between two snapshot sets1. RecoverPoint uses the output of the DIFF command to read the actual data and transfer it to the target side1.

The other options provided are not typically used for this purpose:

SCSI DELTA is not a recognized SCSI command2.

SCSI TRANSFER is not a recognized SCSI command3.

SCSI UPDATE is not a recognized SCSI command4.

Therefore, the verified answer is A. SCSI DIFF, as it is the SCSI instruction used to build a bitmap of the changes between the first snapshot and subsequent snapshots when RecoverPoint is used with XtremIO1.

Explanation:

In a multi-cluster environment managed by the same XtremIO Management Server (XMS), a storage administrator can navigate between different XtremIO clusters using the WebUI through the Inventory List. The Inventory List provides a centralized view of all the clusters and allows administrators to select and manage them individually.

The process for navigating to different clusters is as follows:

Log into the XtremIO WebUI using the appropriate credentials.

Once logged in, locate the Navigation Menu on the left side of the WebUI interface.

In the Navigation Menu, find and click on the Inventory List button. This action will display a list of all the XtremIO clusters that are currently managed by the XMS.

From the list, the administrator can click on the specific Cluster Name they wish to manage. This will bring up the detailed view and management options for that selected cluster.

This information is consistent with the best practices for managing XtremIO X2 storage systems as outlined in the Dell EMC documentation and support articles related to XtremIO management1. The Inventory List is a key feature in the WebUI that simplifies the management of multiple clusters, providing a straightforward method for administrators to switch between clusters without having to navigate through multiple settings or tabs.

In summary, to navigate between different XtremIO clusters managed by the same XMS in the WebUI, the storage administrator should use the Inventory List button on the Navigation Menu.

Explanation:

Explanation:

The LUN queue depth setting per path in a customer's environment configured with a dual X-Brick cluster, 8 ESXi hosts with 2 Emulex HBAs, each ESXi host having 8 LUNs, and each LUN visible through 4 paths, should be set to 1281.

This is based on the best practice recommendation for Emulex HBAs in an XtremIO environment, as mentioned in the Dell Community1. The LUN queue depth on the Emulex HBA should be set to 1281. However, this setting might need to be adjusted based on the specific storage environment and the other storage arrays that are being used12.

Explanation:

For a customer who wants to design an XtremIO solution for an Oracle RAC application environment, maintains two data centers, and requires replication to a third site for disaster recovery purposes, the recommended Dell EMC technology is MetroPoint1.

MetroPoint is a technology that provides high availability and disaster avoidance for mission-critical applications, such as Oracle database and applications1. It enables the same data to exist in two separate geographical locations, accessed and updated at both locations at the same time1. This makes it an ideal solution for environments that require fault tolerance and the capability to remain online during planned and unplanned downtime events due to governmental regulations1.
